Valve, PVRV, Flanged, 6", 5oz
Valve, PVRV, Flanged, 6", 5oz
$4,192.71 (USD)
Location:Pennsylvania
Available quantity:1
or
Call 1 (844) 564-4237
Description
The Enardo 953-6-1111-Z0.5-F is a specific 5oz configuration of the Enardo™ 953 Series High-Performance Vacuum Relief Valve, designed for side-mount applications where vacuum protection is critical. Here's a detailed breakdown of what this model offers:
General Description: Enardo 953 Series
The 953 Series is engineered to:
- Protect tanks and process systems from vacuum conditions that could cause structural damage.
- Prevent product loss due to evaporation.
- Contain hazardous or odorous vapors, improving environmental safety.
It features the Enardo Saber® Guide valve system, which ensures smooth valve stroke and minimizes wear, and uses Polyphenylene Sulfide (PPS) for the seat and pallet—an advanced thermoplastic known for its resistance to:
- Corrosion
- Chemical attack
- Temperature extremes (−50°F to 500°F)
- Sticking due to valve seat freeze
Specifications
| Manufacturer | Enardo |
| Model | 6", 5oz |
| Condition | New |
| Stock Number | 953-6-1111-Z0.5-F |
| Conection type | RF ANSI 150 |
| Connection Size (in.) | 6 |
| Valve Type | PVRV |
| Valve Size (in.) | 6x6 |
| Body Material | Cast Aluminum |
| Max Working Pressure (oz) | 5oz |
| Notes | Unused New Surplus |
| Origin Code | OC01 |
| Subcategory 2 | PVRV (Pressure Vacuum Relief Valve) |
| Warehouse Location | TX-B1-2-C-2-L |
| Shipping dimensions (in.) | 13"Lx11Wx14"H |
| Weight (lbs.) | 20 |
