Gauge Assembly, Level, Liquid, 1/2"x18-3/4", 2630#

• Tempered borosilicate glass, Maxos® brand

• Gage body (wetted) per NACE

• Cover flanges, powder coated steel (Standard)

or stainless

• B7 bolting, zinc plated (standard)

• B7M de-rate 20%

• B8M Class 2, de-rate 15%

• Flexible graphite seal / compressed fiber cushion • Cross Ties for added strength, undercut permits

“behind-the-bar’ vision for complete view, design validated by FEA

• Gage support for long / heavy gages (either factory- welded brackets or lift-from-below angle plate)

• Large thru-bore (0.59 Ø) between sections allows brush access for cleaning
